location：Home > Products > Anchor drilling rig > KS900 Top Hammer Anchor Drilling Rig<

KS900

KS900 Top Hammer Anchor Drilling Rig

TEL : +8618029255858

Product Features Product parameters

When drilling through layers such as pebble-filled soil, gravel, mixed soil, and sand layers that are prone to coll apse, use an impact drill to achieve rapid drilling.

1. KS900 Anchor drilling rig stable and reliable performance, suitable for pit anchor, slope support, high-pressure rotary spraying, submerged hole into the rock, miniature pile and so on.

2. Shaogang national standard steel, the material is sufficient, thick, the whole vehicle is stable, with a sense of power, to adapt to a variety of complex and large working conditions.

3. Internationally renowned hydraulic system, Italy Kespa, the United States Eaton, HydraForce, etc; to ensure the reliability of the hydraulic system pressure, flow, internal consumption, the use of more durable, efficient, more accurate and smooth operation.

4. Ergonomics of the design of the set of walking devices to reduce the long distance walking to reduce the operator's work intensity; increase the line of sight, reduce safety hazards.

5. Universal chassis for excavators, supporting wheels, driving teeth, chain rails, large flow rate and large tonnage travel motors, stable and efficient construction even in harsh working conditions.

KS900 Multifunctional Anchor Drilling Rig Technical Parameters

Drilling range	Φ100mm-Φ300mm
Maximum drilling depth	down-the-hole drilling 300M
Power head speed	0-110r/min
Power head torque	15000n.m
Push stroke	3600mm
Horizontal drilling height	3000mm
Maximum opening of clamping rod	300mm
Compensating stroke of push beam	1260mm
Maximum lifting force	10T
Maximum pushing force	4T
Max. lifting speed	23M/min
Max. propulsion speed	50M/min
Frame swivelling angle	±179
Frame height above ground	335mm
Overall power (electric)	55KW+55KW
Input pressure	380V 50Hz
Transport size	6.6x2.2x2.6M
Design weight	10T
